UMT-2D

  Copy


More Options: Make a Folding Card




Storyboard Description

This storyboard does not have a description.

Storyboard Text

  • This is the UMT-2D, it is a Multi-Button & MIDI Converter. It enables external control of playback software, including QLAB, CSC, SFX, SCS, Ableton and similar packages
  • Plug the UMT-2D into the computer using a USB cable.
  • and the 2 LEDs will turn green, telling you the UMT2D is receiving power and is active
  • There are 2× 3-Pin XLR inputs with over-voltage protection, for external push button triggering, for example MD Start/Stop boxes
  • The activity LED will briefly flash red when a button is pressed
  • Plugs the USB into the UMT2D and shows the LED both going green
  • Plugs in a rem2,
  • SPLIT SCREEN One showing the UMT2D LED flashing one showing a hand pushing the button
  • There is one 9-Pin D-SUB connector to allow you to connect button panels or trigger boxes, for example the Nemesis REM8.
  • CSC screen shot of the UMT2D input configuration
  • Here is an example of the UMT2D working in CSC
  • SPLIT SCREEN CSC input /out put monitor shows midi monitor while smaller screen shows buttons being pressed
  • In addition to the button options there is a 9 pin mini din which provides MIDI IN/MIDI OUT as well.
  • Plugs in a rem8
  • SPLIT SCREEN Button capture in Qlab
  • Here you can see the UMT2D working with Qlab
  • Connects the MIDI break out cable
  • Simply connect the break out cable and you have 1 MIDI in and MIDI Out
  • NEMESIS UMT-2D Available from Orbital Sound and selected retail partners
