SEJ101 Design Project
Storyboard Text
- How's things going at the quarry?
- Things are going pretty well, although we keep having problems with the jaw crusher getting jammed
- Whats causing jaw crusher to frequently jam? Are you overfeeding the material?
- No, it's more to do with the inconsistencies in rock size after blasting and the larger rocks cause it to jam
- Ohh, I understand now. Have you ever considering getting a screen bucket?
- A screen bucket?What is that?
- It's a specialised bucket with a square mesh pattern designed to screen material with every scoop
- Really? Sounds like just what I need. Have you got a photo of it?
- Yeah, here it is.
-
- That looks perfect for what I need. How does it work?
- I can show you. You simply attach the bucket to your excavator boom like this
- Wow, that's impressive and so easy to use!
- Yep, it's effectively doing 2 things at once. With every scoop you screen material and can create a separate pile of large rocks to use the rock hammer on
- That's perfect for what I need. Now the jaw crusher won't get jammed!
- Awesome, that's one of the specific uses it was designed for.
- Thank you. It will definitely save me some headaches in the future.
